Spring-Loaded Top Catch Bracket for Sliding Door – Model 1410.4.05130
- Status: Out of stock
- Vendor: Vinahardware
Contact
Spring-Loaded Top Catch Bracket for Sliding Door – Model 1410.4.05130
Vinahardware® | Steel + POM | Push-pin mechanism | For furniture sliding doors
| Item | Specification |
|---|---|
| Housing | 1.5 mm cold-rolled steel (SPCC), black powder-coat |
| Stop pin | Ø5 mm brass, spring-loaded |
| Guide bush | POM engineering plastic, self-lubricating |
| Overall size | 56 mm (L) × 44 mm (W) × 11 mm (H) |
| Mounting pattern | 4 × Ø5 mm round holes + 2 × slot 5 × 10 mm (32 mm c-c) |
| Spring force | 18 ± 2 N (release) |
| Rated door weight | ≤ 40 kg per leaf (used with Vinahardware rollers) |
| Finish options | Black (standard) • White • Zinc |
| Custom services | Logo laser, blister pack, colour on request |
Key Advantages
-
All-in-one stop & locator – prevents over-travel, keeps doors flush.
-
Quiet operation – POM bush absorbs impact, no metal-to-metal noise.
-
Fast mounting – elongated slots compensate drilling tolerance ±2 mm.
-
Durable coating – 240 h salt-spray, suitable for kitchen humidity.
-
Fully tested – 50 000 open/close cycles per Vinahardware QC-06.
Typical Applications
Wardrobe sliding doors • Kitchen cabinet shutters • Media console covers • Pantry & utility closets
MOQ / Lead Time
| Item | Detail |
|---|---|
| MOQ | 5 000 pcs |
| Lead time | 20 – 25 working days after deposit & drawing approval |
