Model No.: 3600.4.04592 | Brand: VINAHARDWARE
Product Overview
The VINAHARDWARE 3600.4.04592 twin-arm hook is pressure-die-cast from solid zinc alloy and plated in a durable satin-nickel finish that suits modern, Scandinavian and transitional interiors. Its compact 50 mm body carries two smoothly radiused arms that protect delicate fabrics while offering ample hanging capacity for coats, bags and towels.
Parameter | Specification |
---|---|
Height (overall) | 50 mm |
Width (arm tip-to-tip) | 65 mm |
Projection | 34 mm |
Material | Zamak-3 zinc alloy, one-piece casting |
Finish | Satin nickel, 10 µm Ni + clear lacquer |
Mounting holes | 2 × Ø 5 mm countersunk, 25 mm centre-to-centre |
Static load rating* | 15 kg / hook (*vertical pull, concrete substrate) |
Operating temp. | –10 ℃ … +60 ℃ |
Compliance | ISO 9001:2015 • RoHS |
Key Advantages
One-piece construction – no weld seams, excellent torsional strength.
Fabric-friendly tips – rounded Ø 9 mm ends prevent snagging.
Corrosion resistant – satin-nickel plating endures ≥ 72 h salt-spray.
Fast mounting – includes #8 × 30 mm nickel screws and wall plugs.
OEM flexibility – matte black, antique brass or PVD gold, plus laser logo in ≤ 15 days.
Typical Applications
Hallway coat racks • hotel bathrooms • café rest rooms • closet organisers • boat cabins.
MOQ & Lead Time
MOQ 1 000 pcs • 12 – 18 working days after 30 % deposit (7-day rush for repeat orders).
Packaging & Shipping
1 hook + screw set / kraft pouch → 100 pcs / inner box → 600 pcs / 5-ply carton 46 × 32 × 19 cm (22 kg). Palletised & stretch-wrapped; FSC cartons or retail blister cards available.
Installation Guide
Mark 25 mm hole spacing vertically; drill Ø 6 mm × 35 mm pilot holes, insert wall plugs, drive screws flush, load test at 10 kg.
